Wilden A.025P/PZPPP/TNL/TF/PTV/0151 – 6 mm (1/4″) Accu-Flo™ Clamped Plastic Pump

OVERVIEW Accu-Flo™ Series Air-Operated Double-Diaphragm (AODD) Pumps give you the critical external pump control necessary for exacting applications such as batching. Featuring a direct electrical interface that utilizes electrical impulses to stroke the pump instead of differential pressure, the Accu-Flo Series provides a variable stroke rate that you can easily control as needed. To meet your applications, Accu-Flo Series pumps are available as NEMA 5-compliant and come in a variety of voltage options. PERFORMANCE AIR INLET 1/8″ FNPT LIQUID INLET 6 mm (1/4″) LIQUID DISCHARGE 6 mm (1/4″) CONNECTION TYPE NPT/BSPT (Threaded) MAX SUCTION LIFT CAPABILITY Rubber – 4.14 m (13.6′) Dry, 9.33 m (30.6′) Wet PTFE – 3.96 m (13′) Dry, 9.33 m (30.6′) Wet MAX FLOW RATE Rubber – 12.1 lpm (3.2 gpm) PTFE – 11.7 lpm (3.1 gpm) MAX PRESSURE 8.6 bar (125 psi) MAX DIAMETER SOLIDS 0.4 mm (1/64”) DISPLACEMENT PER STROKE * Rubber – 0.02 L (0.005 gal) PTFE – 0.02 L (0.005 gal) * 1 cycle = 2 strokes
